Asperitas DFC

Power and scale not limited by cooling

Asperitas enables the limitless datacentre with Direct Forced Convection (DFC) technology
skip

Asperitas' unique DFC technology enables the most advanced levels of performance and scale. With an impressive cooling capacity beyond 3.6kW per U, even the most power-hungry and heat-intensive components are efficiently cooled.

Business benefits

Enabling the limitless datacentre

Limitless performance

Enabling maximum IT performance with minimum energy overhead and maximum cost and resource efficiency.

Limitless scale

Cleantech solutions which grow in line with an exponential growth path.

Limitless cooling

Support power-hungry and heat-intensive components with focused precision cooling.

Limitless flexiblity

Deployable in any environment through a modular design with maximum configuration options.

Limitless resilience

Enabling always-on workloads with continuous monitoring and integrated autonomous safety features.

Technical Features

Specifically designed to drive and facilitate customers to meet evolving compute demand

BUILT FOR SCALE

The DFC platform scales from as few as 12U

UNPARALLELED SAFETY

Integrated, dual hull tank with temperature and level sensor

UNMATCHED power

Datacentres can stack more powerful servers in a smaller footprint without the risk of overheating

densities exceeding 2000W per socket

CPUs and GPUs can operate at their full potential, free from thermal limitations

SUSTAINABLE

Low carbon footprint and quantified PUE performance visible in real time

PERFECT FIT FOR AI AND HPC WORKLOADS

High power density components precision cooled with extremely low power overhead

Technical specifications

DFC Technical specifications
for your needs

Technical SPECIFICATIONS
Dimensions
600mm x 1,215mm x 1,990mm (L x W x H)
Height clearance requirement
2,440mm
Weight
Product weight: 375kg
Operational weight (without IT): 760kg
Operational weight (with IT): 1,120kg (6-point loads)
ASHRAE W3 solution footprint
105kW/m², 32ºC
Electrical capacity
44kW
Cooling capacity
Exceeding 3.6kW/U
IT capacity (servers)
12U (19” up to 990mm in height)
IT capacity (switches)
2x 19” air-based depth of 480mm
Circulation method
Direct Forced Convection
Liquid product
Single-phase hydrocarbon
Liquid amount (tank full of IT)
Minimum 352 litres
